Dynacord L3600FD

$1,699.00

-

3,600W, 2-channel Power Amplifier with Sonicue-powered DSP

2 in stock

Free Shipping

100% Secure Payment Checkout

The Dynacord L3600FD L-Series FIR-Drive Power Amplifier is a 3600W audio amplifier designed for performing musicians and production companies providing sound reinforcement for live performances in venues including music clubs, community hall events, performance centers, and sports venues. The L3600FD is equipped with a robust power supply and a powerful linear amp design, well suited for the most demanding environments. The sophisticated protection circuitry ensures safe, reliable operation under all conditions.

The L3600FD features SpeakOn connectors for convenient wiring to professional speakers. The amplifier utilizes high-quality components throughout for truly professional processing power and performance characteristics. The on-board DSP includes multi-band PEQs (parametric EQ), crossovers, limiters, and delay per channel. It also has true channel grouping control with extra DSP capabilities like PEQ, GEQ (graphic equalizer), and delay for each group. The Dynacord L3600FD ships with a power cord and USB cable.

  • Live performance DSP amplifier, SpeakOn connectors
  • Fully integrated professional speaker processing with FIR Drive technology
  • Professional acoustic performance and rock-solid reliability
  • Powerful and proven audio performance
  • Engineered for constant stability at 2 Ohms
  • Sophisticated protection circuitry always protects the amplifiers and connected loudspeakers
  • High-performance bulletproof voltage handling
  • On-board DSP includes multi-band PEQs, crossovers, limiters and delay per channel; True channel grouping control with extra DSP capabilities including GEQ
  • Intuitive, powerful control software makes configuration and real time control easy. Up to 16 amp channels can be controlled and monitored simultaneously
  • Advanced FIR drive to optimize loudspeaker settings, providing premium features into an installation form factor
  • Engineered in Germany



  • Number of Channels: 2
  • Power Class: Class H
  • Watts/Side @ 8 ohms: 900W
  • Watts/Side @ 4 ohms: 1700W
  • Watts/Side @ 2 ohms: 3000W
  • Watts Bridged: 6000W @ 4 ohms, 3400W @ 8 ohmns
  • Inputs: 2 x XLR
  • Outputs: 2 x speakON, 2 x XLR
  • Data I/O: 1 x USB Type B (remote DSP control)
  • Cooling System: Front-to-rear, 3-stage-fans
  • DSP: Yes
  • Filters: Yes, FIR
  • Frequency Response: 10Hz-21kHz
  • THD: <0.05% (1200W/4 ohm, MBW=80kHz, 1kHz)
  • Overload Protection: Yes
  • Rack Spaces: 2U
  • Height: 3.50″
  • Depth: 18.2″
  • Width: 19″
  • Weight: 40.1 lbs.
